Specifications

• Product
  Type

  OLED
• Series

  9
• Design
  Design

  Infinity One

  Color

  ?

  TITAN BLACK

  Stand Type

  SLIM OC STAND

  Bezel Type

  4 Bezel-less

  Slim Type

  Ultra Slim

  Stand Color

  Titan Black

  Front Color

  Titan Black
• Video
  Resolution

  ?

  3,840 x 2,160

  Color

  ?

  Perceptional Color Mapping

  HDR (High-Dynamic Range)

  Quantum HDR OLED plus

  Picture Processor

  Neural Quantum Processor 4K

  Viewing Angle

  Ultra Viewing Angle

  Film Mode

  Yes

  Adaptive Picture

  Optimized/EyeComfort

  HLG (Hybrid Log Gamma)

  Yes

  Contrast

  Self-illuminating pixels

  Contrast Enhancer

  Real Depth Enhancer

  HDR10+

  Yes(ADAPTIVE/GAMING)

  Picture Engine

  Neural Quantum Processor 4K

  Motion Technology

  Motion Xcelerator Turbo Pro

  One Billion Color

  Yes

  Picture Clarity

  Yes

  Expert Calibration

  Yes

  Smart Calibration

  Basic

  AI Upscale

  Yes

  Filmmaker Mode

  Yes

  Brightness/Color Detection

  Brightness/Color Detection
• Audio
  Dolby

  ?

  MS12 5.1ch

  Dolby Atmos

  Yes

  Sound Output (RMS)

  ?

  70W

  Woofer

  Yes

  Speaker Type

  ?

  4.2.2CH

  Multiroom Link

  Yes

  Sound

  OTS+

  Q-Symphony

  ?

  Yes

  Active Voice Amplifier

  Yes

  Bluetooth Headset Support

  Yes

  Bluetooth Audio

  Yes

  Dual Audio support (Bluetooth)

  Yes

  Dolby Decoder

  MS12 5.1ch

  Object Tracking Sound

  OTS+

  Adaptive Sound

  Adaptive Sound+

  Buds Auto switch

  Yes
• Features
  One Connect Box

  ?

  One Connect (Y23 4K)

  Eco Sensor

  ?

  Yes

  SmartThings

  Yes

  Caption (Subtitle)

  Yes

  EPG

  Yes

  IP Control

  Yes

  OSD Language

  ?

  English, Spanish, French

  V-Chip

  ?

  Yes

  MBR Support

  Yes

  9:16 Screen Support

  Yes (Need Auto Rotating Accessory, Compatible Model Only)

  ConnectShare™

  Yes
• Inputs & Outputs
  HDMI Connections

  ?

  4

  USB

  ?

  3

  Ethernet (LAN)

  ?

  Yes

  Terrestrial / RF input

  ?

  1/1(Common Use for Terrestrial)/0

  Digital Audio Out (Optical)

  ?

  1
• Power
  ENERGY STAR® Certified

  Yes

  Power Supply (V)

  AC110-120V~ 50/60Hz

  Typical Power Consumption

  115

  Maximum Power Consumption

  305

  Standby Power Consumption

  0.5

  Power Consumption (Max) (W)

  305

  Power Consumption (Stand-by) (W)

  0.5

  Power Consumption (Typical)

  114
• System
  DTV Tuner

  ?

  (US) ATSC 3.0(Canada) ATSC/ClearQAM

  Digital Broadcasting

  ATSC 1.0/3.0, (NEXTGEN TV) ATSC/ClearQAM

  Analog Tuner

  Yes

  DTV Sound System

  Dolby
• Installation Features
  Mini Wall Mount Compatibility

  Yes

  Vesa Wall Mount Compatibility

  ?

  Yes
• Accessory
  Remote

  TM2360E

  Power Cable

  Yes

  User Manual

  Yes

  E-Manual

  Yes

  Remote Controller Model

  TM2360E

  Remote Controller Model Code

  BN59-01432A

  Mini Wall Mount Support

  Yes

  VESA Wall Mount Support

  Yes

  Optional One Connect Cable Support

  Yes

  Slim Fit Wall-mount Support

  Yes

  Zigbee / Thread Module

  Built-in

  Full Motion Slim Wall Mount (Y22) Support

  Yes

  SlimFit Cam Support

  Support

  Studio Stand Support

  Yes

  Auto Rotating Wall Mount Support

  Yes
• Loading Quantity
  40ft HC

  168

  53ft

  228
• VESA Standard
  Screw Size

  M8

  Screw depth

  5-6

  VESA Spec

  400×300
• Eco
  Eco Sensor

  ?

  Yes

  Auto Power Saving

  Yes

  Auto Power Off

  ?

  Yes
• Display
  Inch

  65

  Resolution

  ?

  3,840 x 2,160

  Refresh Rate

  120Hz (Up to 144Hz)

  Anti Reflection

  Yes

  Diagonal Screen Size (Inch)

  64.5
• Smart Service
  Operating System

  Tizen™ Smart TV

  Bixby

  US English, UK English, India English, Korean, French, German, Italian, Spanish, BR Portuguese (features vary by language)

  Far-Field Voice Interaction

  Yes

  Built-in Voice Assistant

  Alexa

  Works With AI Speaker

  Alexa, Google Assistant

  TV Plus

  Yes

  Web Browser

  Yes

  SmartThings Hub / Matter Hub / IoT-Sensor Funtionality

  Yes

  Samsung Health

  Yes

  Universal Guide

  Yes (US only)

  Media Home

  Yes
• Smart Features
  Multi Device Experience

  TV to Mobile, Mobile to TV, TV initiate mirroring, TV Sound to Mobile, Sound Mirroring, Wireless TV On

  Video Communication

  Google Meet

  Tap View

  Yes

  Multi View

  Up to 2 videos

  Music Wall

  Yes

  Mobile Camera support

  Yes

  Easy Setup

  Yes

  App Casting

  Yes

  Ambient Mode

  Ambient Mode+

  Workspace

  Yes

  Wireless Dex

  Yes

  Web Service

  Microsoft 365

  Chat Together

  Yes (US only)

  ConnecTime

  Yes (US only)

  Telemedicine

  HealthTap (US only)
• Game Feature
  Auto Game Mode (ALLM)

  Yes

  Game Motion Plus

  Yes

  Dynamic Black EQ

  Yes

  Surround Sound

  Yes

  Super Ultra Wide Game View

  Yes

  Game bar 3.0

  Yes

  Mini Map Zoom

  Yes

  Light-Sync

  Yes

  FreeSync

  FreeSync Premium Pro

  HGiG

  Yes

  Gaming Hub

  Yes (KR, US, CA, BR, GB, FR, DE, IT, ES)
• Connectivity
  HDMI

  4

  HDMI (High Frame Rate)

  4K 144Hz (for HDMI 1/2/3/4)

  HDMI Audio Return Channel

  Yes

  USB

  ?

  3

  USB-C

  1

  Ethernet (LAN)

  ?

  Yes

  Digital Audio Out (Optical)

  ?

  1

  RF In (Terrestrial / Cable input / Satellite Input)

  1/1(Common Use for Terrestrial)/0

  Ex-Link ( RS-232C )

  1

  WiFi

  Yes (WiFi5)

  Bluetooth

  ?

  Yes (BT5.2)

  Anynet+ (HDMI-CEC)

  Yes
• Accessibility
  Voice Guide

  US English, Mexico Spanish, Canada French, Finnish, German, Greek, Hungarian, Italian, Norwegian, Polish, Portugal Portuguese, Romanian, Slovak, Swedish, Czech, Danish, Dutch, Korean

  Learn TV Remote / Learn Menu Screen

  US English, Mexico Spanish, Canada French

  Low Vision Support

  Zoom Menu and Text, High Contrast, SeeColors, Color Inversion, Grayscale, Picture Off, Magnification, Relumino Mode

  Hearing Impaired Support

  Multi-output Audio, Caption Position, Sign Language Zoom, Separate Closed Caption, Sign Language Guide, Auto Caption Position

  Motor Impaired Support

  Slow Button Repeat
• Dimension (WxHxD)
  Set Size without Stand (WxHxD)(inch)

  56.8 x 32.7 x 0.4

  Set Size with Stand (WxHxD)(inch)

  56.8 x 35.2 x 10.5

  One Connect Box Size with cover(WxHxD)(inch)

  14.2 x 1.3 x 13

  Package Size (WxHxD)(inch)

  64 x 36.8 x 6.7
• Component
  User Manual

  Yes

  E-Manual

  Yes

  Power Cable

  Yes

  Slim Gender Cable

  Yes
• Stand Dim (WxHxD)
  Stand Size (inch)

  14.2 x 11.7 x 10.5
